Power Commander (15kVA - 450kVA)

Description The Power Commander is a magnetic voltage regulator that provides high precision voltage regulation with high fault clearing capability. With the Power Commander's tight voltage regulation and load regulation, it makes it the best choice for testing as well as high precision voltage applications. Single Phase Sizes:15kVA, 25kVA, 37.5kVA, 50kVA, 75kVA, 100kVA, 150kVA Three Phase Sizes: 15kVA, 22.5kVA, 30kVA, 45kVA, 75kVA, 112.5kVA, 150kVA, 225kVA, 300kVA, 450kVA Features & Benefits Technical Specs Applications FAQ

• High Precision Voltage Regulation
• High Fault Clearing Capability
• Low Harmonic Distortion
• Adjustable Output Voltage
• High Common Mode Noise Attenuation
• Tight Load Regulation
• 20 Year Design Life
• Rugged Design
• No Moving Parts - (except certain models have fans)
• Low Maintenance

• Voltage Regulation: +/- 1%
• Load Regulation: +/- 0.5%
• Input Voltage Window: +10% to -20%
• 100,000 MTBF, 20 Year Design
• Overload Rating: 500% for 10 seconds, 1000% for 1 Cycle
• Efficiency: 95%

• Test Laboratories / Failure Testing / Burn In
• Industrial / Commercial / Institutional Facilities
• Regulated Bypass for Uninterruptible Power Systems
• Semiconductor Manufacturing
• Highly Accuate Voltage Regulation Needs

• How Does the Power Commander Regulate Voltage?
  The Power Commander uses the natural properties of magetics to regulate voltage. The Power Commander changes the magnetic properties of a transfomer through a control loop, thus changing the voltage either up or down.




• What differentiates the Power Commander from Other Regulators?
  The Power Commander can regulate voltage to within 1% of the nominal voltage, most normal voltage regulators are not this precise. The Power Commander also has a load regulation of 0.5%, this means that if the load value is changing constantly then the output voltage will not chnage by more than 0.5% of nominal.
