| TECHNICAL SPECIFICATIONS |
| Output |
| Output Power Capacity |
3375 Watts / 4500 VA |
| Max Configurable Power |
3375 Watts / 4500 VA |
| Nominal Output Voltage |
120V,208V |
Output Voltage Distortion |
Less than 5% at full load |
Output Frequency (sync to mains) |
47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal |
| Crest Factor |
up to 5 : 1 |
| Waveform Type |
Sine wave |
| Output Connections |
(14) NEMA 5-15R
(2) NEMA L6-20R |
| Input |
| Nominal Input Voltage |
208V |
| Input Frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections |
NEMA L6-30P |
| Cord Length |
6 feet (1.83 meters) |
| Input voltage range for main operations |
157 - 255V |
| Input voltage adjustable range for mains operation |
151 - 268V |
| Batteries & Runtime |
| Battery Type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
|
| Typical recharge time |
6 hour(s) |
| Replacement battery cartridge |
CURK12, RBC12 |
| RBC™ Quantity |
2 |
| Typical Backup Time at Half Load |
22.7 minutes (1687.5 Watts) |
| Typical Backup Time at Full Load |
6.4 minutes (3375 Watts) |
| Runtime Chart |
Smart-UPS |
| Communications & Management |
| Interface Port(s) |
DB-9 RS-232,RJ-45 10 Base-T ethernet for web/ SNMP/ Telnet management,SmartSlot |
| Available SmartSlot™ Interface Quantity |
1 |
| Pre-Installed SmartSlot™ Cards |
AP9617 |
| Control panel |
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators |
| Audible Alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
| Emergency Power Off (EPO) |
Optional |
Surge Protection and Filtering
|
| Surge energy rating |
1020 Joules |
| Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
|
| Maximum Height |
20.80 inches (528 mm) |
| Maximum Width |
17.50 inches (445 mm) |
| Maximum depth |
26.20 inches (665 mm) |
| Net Weight |
325.00 lbs. (147.73 kg) |
| Shipping Weight |
360.00 lbs. (163.64 kg) |
| Shipping Height |
25.00 inches (635 mm) |
| Shipping Width |
24.00 inches (610 mm) |
| Shipping Depth |
30.00 inches (762 mm) |
| Color |
Beige |
| Environmental |
Operating Environment |
32 - 104 °F (0 - 40 °C) |
Operating Relative Humidity |
0 - 95% |
| Operating Elevation |
0-10000 feet (0-3000 meters) |
| Storage Temperature |
5 - 113 °F (-15 - 45 °C) |
| Storage Relative Humidity |
0 - 95% |
| Storage Elevation |
0-50000 feet (0-15000 meters) |
| Audible noise at 1 meter from surface of unit |
53 dBA |
| Online Thermal Dissipation |
1708.00 BTU/hr |
| Conformance |
| Regulatory Approvals |
CSA,FCC Part 15 Class A,UL 1778 |
| Standard Warranty |
2 years repair or replace,optional on-site warranties available,optional extended warranties available |
| Equipment protection policy |
Lifetime : $150000 |
| |
